How to make your own DIY Hylian Shield Tutorial PART ONE

October 12, 2014

I’ve already talked about my love for Zelda. Now its time to geek out over my love of making things!

I love working with new or challenging materials. Initially I had wanted to make my shield out of wood, but without a proper workspace, shared walls, and older neighbors, I thought that may prove to be too messy and noisy. I have worked with wood before, but always in a proper workspace. After successfully creating a tiny version of the Hylian Shield, I decided it was time to get started on my FULL SCALE version of the shield!

Step 1: Gather your materials:

Supplies

YOU WILL NEED:

Foamcore (in large unbent pieces): I sourced mine from my local art-supply store. Michaels may have them large enough. Be sure they are at least 20 inches (50 cm) square.

Newsprint: (or other scrap paper) to make your template drawings. Or print them out from images you find online. Be sure to make drawings for the front of the shield AND for the back of the shield.

Pencils and Bold Markers to make your drawings on the newsprint and on the cardboard.

Brads: buy a lot of them, I went through close to 75 of them between both shields..

Glue: I used Aleene’s Tacky Glue and it worked quite well.

Masking Tape: .5 inches to 1 inch wide

Rust-oleum “Hammered” silver spray paint

Rust-oleum Primer (White)

X-Acto #11 Blade and Knife

Scraps of Leather or other durable brown fabric or felt.

Paint and Paintbrushes: I used Martha Stewart’s High Gloss Acrylic Paints and an assortment of brushes

Measuring tools: Ruler, compass, protractor, measuring tape, etc.

Handle: Purchase a drawer/cupboard handle and its hardware from your local hardware store. Be sure to use one that fits your hand nicely. This will be the handle on the back of the shield.

Wooden Buttons: approximately 1.25 inches in diameter. Embellishments on front and back of the shield.

Step 2: Draw out the templates for the front AND back of the shield. Be sure to make them the exact size that you want them to be. For me, that was 20″ tall and 18.5″ (approx. 50 cm by 45 cm). The shield may need to be larger or smaller to suit your needs.

Hylian Shield Tutorial 1

Make sure you include all details too!

Once you’ve drawn out your templates from newsprint, cut along the outside like in the above photo. You’ll save yourself a lot of trouble by cutting the templates out this way. This would be a difficult project to freehand. Next, trace around the templates onto the sheets of foam core using your pencil. Carefully cut along your pencil line to cut out your first part of the shield.

Hylian Shield Tutorial 7

While you’ve got your ruler handy, make some guide lines on the shield to help you orient the template onto the center of the shield. Make one line down the center and another 1/2 way down the shield. Cut out and mark 3 shield parts in the SAME way.

Step 3: Cut out the interior of the FRONT Template. This will assist in keeping the shield pieces symmetrical Using an X-Acto blade will be much easier than trying to use scissors. You will be using the inner pieces as a guide in our next step. Keep all shield pattern pieces.

Hylian Shield Tutorial 2Cut inside this boarder with an X-Acto knife.

Once you have cut out the boarder, place it atop one of your shield pieces. This piece will become the top layer on the front of the shield. Use a tiny bit of masking tape to secure the stencil to the foam-core. Trace the inner boarder with a pencil. Use an X-Acto bade to cut out the design. Save the pieces from the center and set aside.

Hylian Shield Tutorial 5

Make sure you secure the stencil/template or it may shift during tracing/cutting.

Hylian Shield Tutorial 10

Here you can see the stencil/template and the pencil lines. Ready to cut!

Step 4: Do the same thing for the back of the shield.

But here is where things may get a little tricky… or at least different. Depending on the size of your handle and your personal preference, you may give the supporting cross on the back different dimensions. I made the horizontal arm on the cross slightly smaller than the size of the handle. This way, the handle goes around the cross instead of on top of it.

Hylian Shield Tutorial 18

This was cut after careful measurement.

Hylian Shield Tutorial 6

Measure twice, cut once.

Carefully cut out the cross pattern and outer boarder. Make sure that you give the outer boarder a uniform thickness. For my shield, I gave it a 4cm thickness (see photo). This will make it look more finished and will also provide more stability.

Hylian Shield Tutorial 11

I found it helpful to use a ruler to cut straight lines.

Hylian Shield Tutorial 13

Here are the front AND the back of the shield.

Above are the two pieces we just cut atop the two shield pieces we cut from before. We now have two “front” pieces and two “back” pieces. That’s all the major cutting we have to do for today. Next we will add some of the hardware that gives this shield its character and believability. Gather your hardware and tools and meet me back here ASAP!

Getting Ready for Halloween

October 10, 2014

I suppose I have made it pretty clear, but just in case you weren’t sure, I am going to be Link from the Legend of Zelda for Halloween. I’ve never been one to wear ready-made costumes; even as children we always had a handmade costume from Grandma R. As I’ve grown older, I continued that tradition, frequently making my own costumes. I was never really one for following the trends as it were.

Hylian Shield Tutorial 35

The biggest challenge for this year’s costume was not the outfit itself (I basically had that together, save some time to embroider and work on accessories). The biggest challenge this year was Link’s shield and sword. Link is pretty recognizable, but if I were to dress up as Link without his trusty sword and shield…well, that wasn’t an option. I did some research at the beginning of the month to prepare myself for the “real deal” of making or finding a sword and shied that would work for my costume.


Looking online, there are very few options that look good and don’t cost an arm-and-a-leg. Since I need both my arms to swing my sword and use my shield, and since Rupees don’t grow on trees, I decided to make my own Hylian Shield. I styled the design after the shield from Legend of Zelda Twilight Princess. I chose this shield for a few reasons: The materials I had for Link’s tunic matched that character design perfectly, and I really like the way they designed the Master Sword and Hylian Shield in that game. Also, it was the last game where Link was playable as a left-handed character (on the Gamecube version) and I wanted to be true to the “Corrie-Fisted” Link I grew up with!

2465631-the_legend_of_zelda_twilight_princess_link_costume_ver_01-3-03

Concept artwork for Link in Twilight Princess.

Obviously I will share the costume itself, but in the next few posts I will share my progress in the making of the Hylian Shield. If you have any questions, please message me or add a comment. I hope my instructions will inspire other gamer girls (and boys!) to make their own Hylian Shield!

Until next time!

Hylian Shield Tutorial 1

Sketching out to-scale drawings to make the shield.

Tiny Hylian Shield Tutorial Part 3

October 10, 2014

If you need a to-scale example of the size of the shield I showed you how to make, here you go!

This shield is just the right size for my cat, Ferdinand. He is ready to go in to battle with the most ferocious of foes! Watch out!

Tiny Hylian Shield Tutorial  CATHi-yah!

Tiny Hylian Shield Tutorial Part TWO: Steps 6 through 10

October 5, 2014

Yesterday I started showing you how to make your own tiny Hylian Shield from the Legend of Zelda Ocarina of Time. Today I am back to finish up the tutorial.

Step 6: Detailing What would the Hylian Shield be without its fine detailing? A Deku Shield? There are a lot of options for adding details to the center of your shield. With this smaller shield, I chose to use a combination of materials. For the Triforce, I used some thin cardboard. For the bird motif, I used my hot glue gun to paint the design. If you are not very good at freehand-drawing, I would suggest cutting out the design from your template. This was a little tricky, but I am pleased with the results. I may try something different on the larger shield, though.

Tiny Hylian Shield Tutorial 8

The glue gun added a nice texture, but was difficult to control.

Step 7: Prime This is especially important if working with cardbard. The dark surface will be difficult to paint if you do not prime it.

Tiny Hylian Shield Tutorial 9The front after one coat of primer.

Be sure to get the front and the back. Let it dry completely between coats if a second coat is necessary.

Tiny Hylian Shield Tutorial 10The back of the shield after one coat of primer.

Step 8: Spray Paint Now it’s time for the fun part. Once you’ve let your coat of primer dry completely, you can add a coat of your Hammered Spray Paint. This paint is textured and does a great job of covering most surfaces evenly. I did not have any problems with my shield, but you may need to touch-up or add a second coat of paint. Be patient and let each coat dry before applying the next one.

Also, if you did cover the outside of the shield with masking tape, bear in mind that the paint will remain tacky there for a little while longer than it does on the cardboard. Be mindful of this when setting the shield down on surfaces while it dries.

Paint both sides of the shield.

Tiny Hylian Shield Tutorial 12Shield front after one coat of Hammered Silver paint.

Step 9: Paint and Detail. Once your silver paint has dried, it is time to add detail to the shield. I used a variety of small brushes and my acrylic paints to add the color to the front of the shield. I did the blue base first and then painted the red bird and Triforce, leaving the silver parts

Tiny Hylian Shield Tutorial 13

Carefully adding blue paint.

Tiny Hylian Shield Tutorial 14

Don’t forget to paint the back!

You may need to add several coats of paint. Depending on the type of paint you are using, you may also want to cover the shield in a clear gloss coat. As all of my paints were glossy, I did not do that for my shield. Once the paint has dried on the front and the back, it is time to add some hardware. On this small shield, I added a little loop to be used to hang or secure the shield. On a standard-size shield, it is even more important to add the correct hardware. This small loop will do for now, but if you make a larger shield in the future, be sure to make the straps and handle more secure.

Tiny Hylian Shield Tutorial 15

Brads have proven to be very useful for this project.

Step 10: Sit back and admire your handy-work. Even if you have never touched a tool in your life, this project can be easy enough for any skill level. While this shield may not be big enough to defend yourself from even the smallest of Deku Shrubs, it is cool enough to display in your home or office. Many materials are ones that you may have on-hand.

17

Tiny Hylian Shield Tutorial 16

With the leather loop on the back, you can easily hang this small shield somewhere where it can be seen!

I hope this tutorial was helpful! If you have any questions regarding the instructions or photographs please let me know. Share your finished projects too!!!

Want to see STEPS 1 – 5? Click here!

Tiny Hylian Shield Tutorial Part One: Steps 1 through 5

October 4, 2014

The other day I mentioned that I would be working on a DIY tutorial project. For those of you who guessed that I would be making a Hylian Shield, you are right! Congrats! I am going to be Link for Halloween, and I thought now is as good a time as ever to try my hand at writing an online tutorial for like-minded gamer girls!

Tiny Hylian Shield Tutorial 5

Now, I am a rather practical and analytical person. I love working with new or challenging materials. Initially I had wanted to make my shield out of wood, but without a proper workspace, shared walls, and older neighbors, I thought that may prove to be too messy and noisy. I have worked with wood before, but always in a proper workspace like a garage or studio. I was also taught to “measure twice, cut once,” so I decided to make a small-scale version of the shield to get the materials and measurements right. These instructions will be for how to make a small “display” Hylian Shield measuring approximately 6.5 inches by 5.5 inches (16 x 14 cm).

Step 0: Decide which version of the Hylian Shield you would like to make. For the small shield I chose to make the shield from the Legend of Zelda Ocarina of Time. For my larger shield, however, I will be using the designs from the Legend of Zelda Twilight Princess.

Step 1: Gather your materials:

Supplies

YOU WILL NEED:

Cardboard (in large unbent pieces): I sourced mine from my local grocery store.

Newsprint: (or other scrap paper) to make your template drawings. Or print them out from images you find online. Be sure to make drawings for the front of the shield AND for the back of the shield.

Pencils and Bold Markers to make your drawings on the newsprint and on the cardboard

Brads: buy a lot of them, I went through close to 75 of them

Glue: I used Aleene’s Tacky Glue and it worked quite well

Masking Tape: .5 inches to 1 inch wide

Rust-oleum “Hammered” silver spray paint

Rust-oleum Primer (White)

X-Acto #11 Blade and Knife

Scraps of Leather or other durable brown fabric

Paint and Paintbrushes I used Martha Stewart’s High Gloss Acrylic Paints and an assortment of brushes

Measuring tools: Ruler, compass, protractor, measuring tape, etc.

Step 2: Make the shield base. Take your template drawing and trace it out on the cardboard three times.

Tiny Hylian Shield Tutorial 1

Make sure you leave a little room around each piece to be able to cut safely.

This will create the piece for the front of the shield, the body of the shield, and the detailing for the back of the shield. Once you have traced and cut out the three pieces, cut out the outside boarder for the front of the shield. Use your template and cut out the inside design of the shield, leaving just the boarder as shown in the image below.

Tiny Hylian Shield Tutorial 4This will help give the shield more depth.

Step 3: Cut out the front and back pieces. Use your Xacto Blade to carefully cut around your templates to make the front and the back of the shield.

Step 4: Secure the shied pieces together. Using brads and glue, you will be making sure that this shield is as durable as possible. It is important to measure out where you want your brads to go to adorn both the front and back of the shield. They add a nice aesthetic, but they also serve to keep the several pieces of the shield from separating. I measured out the places where I wanted to put the brads and marked them with pencils. I found the brads were easier to push into place when I made a small cut with my blade as shown in the image below.

Tiny Hylian Shield Tutorial 6

Sandwich the pieces together and use some of your glue of choice to make sure the pieces don’t go anywhere. I found it helpful to add a little glue to the hole where the brad was placed too.

Step 5: Tape it up. Once all the pieces are sufficiently glued together and brads are placed, flip the shield over and view from the side. Here is the downside of using corrugated cardboard: The edges are rough and porous. You will want to use your masking tape and run it around the outside of the shield. This will give the edges a finished look and will protect your shield from damage on the side. Trim the corners so that the tape does not bunch up too much.

Tiny Hylian Shield Tutorial 7

You could also fill the holes with hot glue, but the tape is easier and cheaper.

Tiny Hylian Shield Tutorial tape

The shield with 1/2 inch masking tape around the edges.

The tape adds a nice finished edge without taking away from the shield itself. It also protects the sides and keeps gunk from getting in there. Stay tuned next time for how to complete your shield!

Here is one more hint

October 3, 2014

Now, I suppose I should give you one more hint. I posted some of the supplies that I will be using for a project earlier today, but let’s give you all one more hint:shield pieces

These three pieces are cut from cardboard.

Here is a photograph of the DIY project I am working on in one of its earliest stages. Does this help? Keep the guesses coming! I will be sure to let you know what I am working on in the next couple days. I will be posting lots of step-by-step photographs and instructions so that you can follow along at home!

Can You Guess What I Am Making

October 3, 2014

This October I will be working on a couple DIY projects. In the spirit of Halloween, they will have a similar theme. I am wondering if you can guess what I will be making based on the supplies I am using!

Supplies

These are most of the supplies I will use. I will also be using larger materials like paper, cardboard, and foam-core.

HEY LISTEN! Here are a few hints:

It’s something that you can hold. It won’t be too big nor too heavy, unless you are quite young.

It’s something that I’ve talked about before on this blog.

3 is an important number.
